PX-6AX GEN3
Disruptive Haptic Technology, Fully Upgraded
Millions of Samples per Second
Ultra-fast tactile sampling for transient signal capture
Repeatability ＜0.5%FS
Superior stability & consistency
15 Physical Information Interpretations
Smarter environmental interaction
0.01N
High-Precision measurement across the full range
In-Factory Calibration
Highly integrated intelligent tactile sensing
Stray Field Immunity in Chip-Level
Boosts anti-interference capabilities
Up to 10 million continuouspressing and release cycles
Industrial-Grade lifespan for long-term endurance
IP68
Top-Tier dust and water resistance
Multidimensional Data, Multimodal Perception
Full Hand Coverage from Fingertip-Finger to Pad-Palm with 12 models, Flexible Performance Options With Tiered Pricing
Elite Series
Fingertip Tactile Sensor
Specifications：18*13*10mm
PX6AX-GEN3-DP-S1813-Elite
Fingertip Tactile Sensor
Length：18mm
Width：13mm
Height：10mm
Fingertip Tactile Sensor
Specifications：20*15*10mm
PX6AX-GEN3-DP-S2015-Elite
Fingertip Tactile Sensor
Length：20mm
Width：15mm
Height：10mm
Finger Pad Tactile Sensor
Specifications：16*10*8mm
PX6AX-GEN3-IP-S1610-Elite
Finger Pad Tactile Sensor
Length：16mm
Width：10mm
Height：8mm
Palm Tactile Sensor
Specifications：20*20*8mm
PX6AX-GEN3-MC-M2020-Elite
Palm Tactile Sensor
Length：20mm
Width：20mm
Height：8mm
Core Series
Fingertip Tactile Sensor
Specifications：18*13*10mm
PX6AX-GEN3-DP-S1813-Core
Fingertip Tactile Sensor
Length：18mm
Width：13mm
Height：10mm
Fingertip Tactile Sensor
Specifications：27*16*13mm
PX6AX-GEN3-DP-S2716-Core
Fingertip Tactile Sensor
Length：27mm
Width：16mm
Height：13mm
Integrated Fingertip & Pad Tactile Sensor
Specifications：30*13*10mm
PX6AX-GEN3-DP-S3013-Core
Integrated Fingertip & Pad Tactile Sensor
Length：30mm
Width：13mm
Height：10mm
Finger Pad Tactile Sensor
Specifications：23*24*8mm
PX6AX-GEN3-IP-M2324-Core
Finger Pad Tactile Sensor
Length：23mm
Width：24mm
Height：8mm
Finger Pad Tactile Sensor
Specifications：30*25*8mm
PX6AX-GEN3-CP-M3025-Core
Finger Pad Tactile Sensor
Length：30mm
Width：25mm
Height：8mm
Omega Series
Fingertip Tactile Sensor
Specifications：28*26*14mm
PX6AX-GEN3-DP-M2826-Omega
Fingertip Tactile Sensor
Length：28mm
Width：26mm
Height：14mm
Fingertip Tactile Sensor
Specifications：35*30*15mm
PX6AX-GEN3-DP-L3530-Omega
Fingertip Tactile Sensor
Length：35mm
Width：30mm
Height：15mm
Finger Pad Tactile Sensor
Specifications：53*25*8mm
PX6AX-GEN3-CP-L5325-Omega
Finger Pad Tactile Sensor
Length：53mm
Width：25mm
Height：8mm
Product Parameters
Output Signals
Triaxial force array, triaxial resultant force, triaxial resultant torque
Number of Force Signals in Array
Maximum 717
Range of Force
0 ~ 25 N ( normal ), ± 10 N ( tangential )
Operating Temperature
0 - 50°C
Overload Temperature
-20 ~ 120°C
Flame retardant grade
V-0 ( the highest UL94 flame classification ) *
Service Life
Supports over 10 million cycles *
Sampling Rate
1 MHz
Maximum Output Frequency
1000 Hz *
Minimum recognition force
0.01 N *
Spatial Resolution
0.1 mm *
Safe Overload
200%
Shock Overload
300%
Repeatability
＜0.5%FS
Water and Dust Resistance
IP68
Stray Magnetic Field Immunity
Chip-level anti-magnetic capability
Operating Voltage
3 to 5 volts
Surface Coverage
Comprehensive coverage on the frontal and lateral curved surfaces
Dynamic Temperature Compensation
Possessing
Torque Perception
Support torque measurement at any point
*Data from PaXini Tech Lab.
